Pista Linear Pista Linear Light Flaps Track 48V1136 1x

13451132
FFD_ LED 2700K DALI DI Black Structure
17W 729lm 42lm/W CRI90
Pista Linear Light Flaps Track 48V 1136 1x
Data sheet Technical support
Request a quote
Specifications Smart Lighting Accessories Compatible with Downloads

Specifications
LINED_134501XX_02.pdf
Light Source Type
LED
Lamp Included
Yes
Input Voltage
48vdc
IP Rating
20
Luminous flux per lamp (lm)
729
Luminaire Power (W)
17
Efficacy (lm/W)
42
Glare Rating (UGR)
15
  • 3500K and 4000K on request
  • This black Track 48V linear module comes with a black track adapter. Exceptions are only possible on request.
  • This Track 48V luminaire can not be used in the upper part of a Pista Track 48V Profile Suspended Up/Down.
LED Type
LED flexible PCB
Light Sources
1
Colour Temperature
2700K
Binning (SDCM)
3
Lifetime
L80B10 @50,000 Hours
CIE Flux Code
68, 93, 99, 100, 45
Electrical Class
III
Dimming Protocol
Dali
DALI Standard
DALI version-1
Glow Wire Rating
960°C
Indoor/Outdoor
Indoor
Adjustability
Not applicable
Gross Weight (g)
859
Net Weight (g)
447
Light Source Type
LED
Lamp Included
Yes
Input Voltage
48vdc
IP Rating
20
LED Type
LED flexible PCB
Light Sources
1
Colour Temperature
2700K
Binning (SDCM)
3
Lifetime
L80B10 @50,000 Hours
CIE Flux Code
68, 93, 99, 100, 45
Electrical Class
III
Dimming Protocol
Dali
DALI Standard
DALI version-1
Glow Wire Rating
960°C
Indoor/Outdoor
Indoor
Adjustability
Not applicable
Gross Weight (g)
859
Net Weight (g)
447
  • 3500K and 4000K on request
  • This black Track 48V linear module comes with a black track adapter. Exceptions are only possible on request.
  • This Track 48V luminaire can not be used in the upper part of a Pista Track 48V Profile Suspended Up/Down.
Luminous flux per lamp (lm)
729
Luminaire Power (W)
17
Efficacy (lm/W)
42
Glare Rating (UGR)
15

1. Smart Lighting Accessories

Casambi Module 48V

Casambi Module 48V

13470209
Track 48V Dim Module Casambi DALI In Track White Structure
13470232
Track 48V Dim Module Casambi DALI In Track Black Structure
13470302
Track 48V Dim Module Casambi DALI Remote
Casambi Switch

Casambi Switch

13470109
Switch Casambi White
Hue Sensor

Hue Sensor

70000191
Motion Sensor Hue Outside Black
70008054
Motion Sensor Hue White
Hue Switch

Hue Switch

70000213
Switch Smart Button Hue White
70000214
Switch Wall Module Hue
70000223
Switch Dimmer Hue White
Zigbee Module

Zigbee Module

13630200
Dim Module Zigbee DALI

Downloads

Download all ;
  • Datasheet
  • Installation instructions
  • LDT files
  • IES files
  • POLAR files
    • CRI_1013939_PISTA-LINEAR_930.jpg
    • CRI_1013939_PISTA-LINEAR-NIGHT-LIGHT_930.jpg
    • CRI_1013934_PISTA-LINEAR_927.jpg
    • CRI_1014218_PISTA-LINEAR-NIGHT-LIGHT_935.JPG
    • CRI_1014218_PISTA-LINEAR_935.JPG
    • CRI_1013934_PISTA-LINEAR-NIGHT-LIGHT_927.jpg
    • TM30_1014218_PISTA-LINEAR_935.JPG
    • TM30_1013934_PISTA-LINEAR-NIGHT-LIGHT_927.jpg
    • TM30_1013939_PISTA-LINEAR-NIGHT-LIGHT_930.jpg
    • TM30_1013939_PISTA-LINEAR_930.jpg
    • TM30_1013934_PISTA-LINEAR_927.jpg
    • TM30_1014218_PISTA-LINEAR-NIGHT-LIGHT_935.JPG
  • SKP file
  • OBJ file
  • FBX files
  • Line drawings
    • SKP_134506XX_SURF_PISTA-LINEAR-FLAPS-1000-DIM_01.skp
    • OBJ_134506XX_SURF_PISTA-LINEAR-FLAPS-1000-DIM_01.obj
    • 3DS_134506XX_SURF_PISTA-LINEAR-FLAPS-1000-DIM_01.3ds
    • FBX_134506XX_SURF_PISTA-LINEAR-FLAPS-1000-DIM_01.fbx
    • ELABEL_PistaLinear_3000K.pdf
    • ELABEL_PistaLinear_2700K.pdf
    • Declarations_13451132
    • Declarations_13451132
    • Declarations_13451132
  • UKCA declarations

Compatible with

Show
Show
  • +1

Pista Track 48V High Surface

  • +1

Pista Track 48V High Suspended

  • +1

Pista Track 48V High Suspended Up/Down

Pista Track 48V Recessed

Pista Track 48V Recessed Trimless

  • +1

Pista Track 48V Surface

  • +1

Pista Track 48V Suspended
