Split Split WallUp/Down L 1x

12604189
FFD_ LED 2700K Trailing Edge DI White Structure - Gold Anodised
9W 288lm 32lm/W CRI90
Split Wall Up/Down L 1x
Datasheet Technical support
Request a quote
Specifications Smart Lighting Accessories Compatible with Downloads

Specifications
LINED_126041XX_V0.pdf
Light Source Type
LED
Lamp Included
Yes
Input Voltage
230v
IP Rating
20
Luminous flux per lamp (lm)
288
Luminaire Power (W)
9
Efficacy (lm/W)
32
Glare Rating (UGR)
12
LED Type
LED PCB
Light Sources
1
Colour Temperature
2700K
Binning (SDCM)
3
Lifetime
L80B20 @50,000 Hours
Electrical Class
I
Dimming Protocol
Trailing edge
Glow Wire Rating
960°C
Indoor/Outdoor
Indoor
Adjustability
Not applicable
Gross Weight (g)
1550
Net Weight (g)
1500
Light Source Type
LED
Lamp Included
Yes
Input Voltage
230v
IP Rating
20
LED Type
LED PCB
Light Sources
1
Colour Temperature
2700K
Binning (SDCM)
3
Lifetime
L80B20 @50,000 Hours
Electrical Class
I
Dimming Protocol
Trailing edge
Glow Wire Rating
960°C
Indoor/Outdoor
Indoor
Adjustability
Not applicable
Gross Weight (g)
1550
Net Weight (g)
1500
Luminous flux per lamp (lm)
288
Luminaire Power (W)
9
Efficacy (lm/W)
32
Glare Rating (UGR)
12

1. Smart Lighting Accessories

Casambi Module

Casambi Module

13470101
Dim Module Casambi Trailing Edge
Casambi Switch

Casambi Switch

13470109
Switch Casambi White

Downloads

Download all ;
  • Datasheet
  • Installation instructions
  • LDT files
  • IES files
  • POLAR files
  • CRI files
  • TM30 files
    • Declarations_12604189
    • Declarations_12604189
    • Declarations_12604189
  • Line drawings
  • SKP files
    • CAD3D_126041XX_SURF_SPLIT_V0.dwg
    • OBJ_126041XX_SURF_SPLIT_01.obj
    • SKP_126041XX_SURF_SPLIT_01.skp
    • 3DS_126041XX_SURF_SPLIT_01.3ds
    • FBX_126041XX_SURF_SPLIT_01.fbx
  • Energy Label
